Oil-Filled Cast Nylon: The Ideal Material for Self-Lubricating Industrial Parts

What Is Oil-Filled Cast Nylon?

Oil-filled cast nylon is a specialized version of cast PA6G (polyamide 6 – cast nylon) that incorporates lubricating oils into its structure during the polymerization process. This results in a high-performance, self-lubricating engineering plastic ideal for applications with continuous sliding or rotational movement.

The oil does not sit on the surface but is permanently embedded inside the nylon matrix. As the part wears slightly during use, a microscopic amount of lubricant is released to the surface—providing consistent lubrication over time without external grease.

How Is Oil-Filled Cast Nylon Made?

Oil-filled cast nylon is produced using the monomer casting process of ε-caprolactam. During this reaction, selected oils or wax-based lubricants are added directly to the molten material before polymerization occurs.

These oils become chemically bonded or physically dispersed throughout the polymer matrix, offering lasting lubrication properties.

Key Performance Benefits

✅ 1. Self-Lubrication

• Reduces the need for external lubricants (grease, oil sprays)

• Extends the service life of mechanical systems

• Lowers maintenance intervals

✅ 2. Lower Coefficient of Friction

• Provides smoother motion in sliding or rolling contacts

• Reduces energy consumption in motor-driven systems

✅ 3. Superior Wear Resistance

• Outperforms unmodified nylon under dry running conditions

• Reduces surface scarring and noise in moving parts

✅ 4. Chemical Resistance

• Maintains performance in contact with oils, greases, fuels, and mild acids

✅ 5. Moisture Behavior

• Slightly improved water absorption resistance compared to standard cast nylon

Technical Comparison

Common Applications

Oil-filled cast nylon is used across many industries due to its excellent dry-running performance and durability.

Industrial Equipment

• Conveyor rollers

• Wear pads

• Chain guides

Agricultural Machinery

• Sprockets

• Slide blocks

• Custom bushings

Packaging & Automation

• Gears in bottling machines

• Film roller ends

• Vibration-resistant spacers

⚙️ Mechanical & OEM Parts

• Pulley sleeves

• Timing belt components

• Cams and thrust washers

Case Study: Conveyor Rollers

In a high-speed conveyor line, traditional plastic rollers required frequent greasing and replacement due to friction-induced wear. By switching to oil-filled cast nylon rollers:

• Maintenance cycles extended from monthly to biannually

• Noise levels reduced by 40%

• Downtime for re-lubrication was eliminated

Available Forms and Customization

At ZHnylon, we manufacture oil-filled cast nylon in the following standard and custom forms:

• Tubes (e.g., O.D. 72 mm, I.D. 35 mm, Length 1200 mm)

• Rods

• Sheets

• Machined Parts per drawing

Colors: Most commonly green, but custom colors are also available
Grades: Available in food-grade, high-load, and UV-stable variants

Selection Tips

1. Operating Speed: Oil-filled nylon is excellent for high-speed applications due to low heat buildup.

2. Load Conditions: For high static loads, consider glass fiber-filled variants instead.

3. Friction Pairs: Pair with stainless steel or hard plastic surfaces for optimal performance.

4. Outdoor Use: For UV resistance, ask for UV-stabilized oil-filled PA6G.

Conclusion

Oil-filled cast nylon is a cost-effective, low-maintenance material solution for moving parts that require reliable lubrication without external grease. Its low friction, excellent wear resistance, and self-lubricating properties make it a preferred choice in conveyor systems, agricultural equipment, and general industrial use.

At ZHnylon, we specialize in the custom production of oil-filled cast nylon tubes, rods, and machined parts, engineered to meet your specific application needs.

Contact us now to get a quote or discuss technical requirements for your project.
